NCC-1300 PLC Control Honeycomb Board Cross Cutter With Touch Screen Operation

Large Image : NCC-1300 PLC Control Honeycomb Board Cross Cutter With Touch Screen Operation

Product Details:

Place of Origin:	CHINA
Brand Name:	AMC MACHINERY
Certification:	CE
Model Number:	NCC-1300

Payment & Shipping Terms:

Minimum Order Quantity:	1 set
Price:	Negociate
Packaging Details:	Corrugated box and plastic film
Delivery Time:	40 days
Payment Terms:	T/T
Supply Ability:	5 sets /mounth

Contact Now

NCC-1300 PLC Control Honeycomb Board Cross Cutter With Touch Screen Operation

Description

Voltage:	220V Or 380V Or 415V	Color:	Customized
Min. Board Widt:	1300mm	Max. Board Widt:	2500mm
Board Thickness:	8-90mm	Min. Cutting Length:	20mm
Working Speed:	20 Cut/min
Highlight:	PLC Control Honeycomb Board Cross Cutter , Touch Screen Honeycomb Board Cross Cutter

Honeycomb board cross cutter

Model: NCC-1300

Characteristics:

Feeding table with pneumatic front stopper, top pressing roller and side pneumatic flapper
Frequency converter motor control cutting blade
PLC control, operate on touch screen

Specification:

Max. board width	1300mm
Max. board width	2500mm
Max. board thickness	90mm
Min. board thickness	8mm
Minimum cutting length	20mm
Blade diameter	400mm
Working speed	20 cut/min
Total power	6KW
Machine dimensioin	6800x3000x1600mm
Machine weight	900KG
