3.3kw Automatic Bending Flaring Machine PLC control SLKK-250A

I'm Online Chat Now

3.3kw Automatic Bending Flaring Machine PLC control SLKK-250A

3.3kw Automatic Bending Flaring Machine PLC control SLKK-250A
3.3kw Automatic Bending Flaring Machine PLC control SLKK-250A

Large Image :  3.3kw Automatic Bending Flaring Machine PLC control SLKK-250A

Product Details:
Place of Origin: CHINA
Brand Name: AMC MACHINERY
Certification: CE
Model Number: SLKK-250A
Payment & Shipping Terms:
Minimum Order Quantity: 1 set
Price: Negotiate
Packaging Details: Corrugated box and plastic film
Delivery Time: 60 working days
Payment Terms: T/T
Supply Ability: 5 sets per month

3.3kw Automatic Bending Flaring Machine PLC control SLKK-250A

Description
Voltage: 220V Or 380V Or 415V Color: Customized
Paper Diameter Range: 30-126mm Paper Height Range: 70-250mm
Paper Thickness: 0.7-1.5mm Accuracy: ±0.3-0.5mm
Highlight:

Automatic Bending Flaring Machine

,

3.3kw Bending Flaring Machine

Bending Flaring Machine

Model: SLKK-250A





Characteristics:

  • It is mainly used in the inner edge-rolling process of paper cans or the enlargingprocess of the front and the front ends of sealing cans. It can switch different working modes to realize multi-purpose of one machine.
  • Compatible 360 degree inner roll forming die perfectly conceals the paper tube incision, enhances the mouth hardness, and effectively reduces the forming fold rate.
  • The design and operation of automatic feeding and discharging is very convenient,and the adjustable atomizing lubrication injection system is equipped. There is nooil residue in the moulding mouth after moulding, which effectively improves the moulding reliability.
  • The main body is made of high strength aluminium profile frame and stainless steel sheet metal. Its shape is compact, concise and beautiful, which meets the requirements of food grade and hygiene in various industries.



Specification:

Model SLKK-250A
Diameter range Φ30-126mm
Height range 70-250mm
Paper thickness 0.7-1.5mm
Accuracy ±0.3-0.5mm
Feeding method 8-station cam split
Storage quantity 20-30pcs
Rated power 3.3kw
Host speed 0-1400 speed
Machine weight 620kg
Dimensions 380*110*180cm
Power voltage 220v 50Hz
Air pressure 0.4-0.6kpa
speed 40-60 pcs/min
control method PLC
people 1 person
Molding Lubricant 50#silicone oil
