Manual Feeding Flute Laminating Machine 7kw BZJ-1450Q2 4000kg Weight

I'm Online Chat Now

Manual Feeding Flute Laminating Machine 7kw BZJ-1450Q2 4000kg Weight

Manual Feeding Flute Laminating Machine 7kw BZJ-1450Q2 4000kg Weight
Manual Feeding Flute Laminating Machine 7kw BZJ-1450Q2 4000kg Weight

Large Image :  Manual Feeding Flute Laminating Machine 7kw BZJ-1450Q2 4000kg Weight

Product Details:
Place of Origin: CHINA
Brand Name: AMC MACHINERY
Certification: CE
Model Number: BZJ-1450Q2
Payment & Shipping Terms:
Minimum Order Quantity: 1 set
Price: Negotiate
Packaging Details: Corrugated box and plastic film
Delivery Time: 40 working days
Payment Terms: T/T
Supply Ability: 5 sets per months

Manual Feeding Flute Laminating Machine 7kw BZJ-1450Q2 4000kg Weight

Description
Power Supply: 380V OR 220V OR 415V Color: Customized
Max. Sheet Size: 1450 X 1300 Mm Min. Sheet Size: 320 X 450 Mm
Working Speed: 0-90 Pcs/min Laminating Accuracy: +/-1.5 Mm
Voltage: 220V Or 380V Or 415V
High Light:

Manual Feeding Flute Laminating Machine

,

Flute Laminating Machine 7kw

Manual feeding flute laminator

Model: BZJ-1450Q2



Characteristics:

  • Vacuum suction for bottom sheet feeding and manual feeding for top sheet.
  • Double frequency convertor and PLC are used to control feeding.
  • Synchronous belt for transmitting, can keep high laminating precision.
  • Curved sheet can be processed on this machine.
  • Can do both 2-ply + 2-ply laminating and 4-ply + 1 top sheet laminating.



Specification:

Model BZJ-1450Q2
Max. sheet size

1450 x 1300 mm

Min. sheet size

320 x 450 mm

Working speed 0-90 pcs/min
Laminating accuracy +/-1.5 mm
Power 7kw
Dimension

8800x2350x1700mm

Weight About 4000kg
