Product Details:
|
Power Supply: | 380V OR 220V OR 415V | Color: | Customized |
---|---|---|---|
Max. Paper Size: | 1450 X 1450 Mm | Min. Paper Size: | 400 X 350 Mm |
Thickness Of Top Sheet: | 120-600g/m2 | Thickness Of Bottom Sheet: | 0.5-10 Mm |
Speed: | 30~170m/min | ||
High Light: | High Speed Lamination Machine 50HZ,AC 380V High Speed Lamination Machine,50HZ Lamination Machine For Paper |
Classic High-speed Laminator
Model: SDX-1450
Back feeder-Technical Data:
Model | SDX-1450 |
Max.Paper size | 1450*1450mm |
Min.Paper size | 400*350mm |
Thickness of top sheet | 120-600g/m2 |
Thickness of bottom sheet | 0.5-10mm |
Speed | 30~170m/min |
Accuracy | ±1.5mm |
Machine Weight | 7000Kgs |
Dimension(L*W*H) | 12720*2492*2630mm |
Power | AC380V/50HZ/26kw |
Suitable Paper | Single face (flute A-G), Muti-Ply (3-7) corrugated cardboard, gray paperboard, paperboard over 300gsm |
Machine Layout:
Model | SDX-1450 (1450*1450mm) |
A | 2630 |
B | 2164 |
C | 1772 |
D | 1610 |
E | 5724 |
F | 1450 |
H | 12720 |
I | 2492 |
