PLC Hydraulic Driving Edge Board Re Cutter 4.5KW Double Edge Cutting Machine

PLC Hydraulic Driving Edge Board Re Cutter 4.5KW Double Edge Cutting Machine
PLC Hydraulic Driving Edge Board Re Cutter 4.5KW Double Edge Cutting Machine

Large Image :  PLC Hydraulic Driving Edge Board Re Cutter 4.5KW Double Edge Cutting Machine

Product Details:
Place of Origin: CHINA
Brand Name: AMC MACHINERY
Certification: CE
Model Number: RC-100D
Payment & Shipping Terms:
Minimum Order Quantity: 1 set
Price: Negotiate
Packaging Details: Corrugated box and plastic film
Delivery Time: 60 working days
Payment Terms: T/T
Supply Ability: 5 sets per month

PLC Hydraulic Driving Edge Board Re Cutter 4.5KW Double Edge Cutting Machine

Description
Voltage: 220V Or 380V Or 415V Color: Customized
Max. Continuous Cutting Speed: 6000mm/min Edge Protector Size: 25-100mm
Max. Cutting Thickness: 8mm
High Light:

Hydraulic Edge Board Re Cutter

,

PLC Edge Board Re Cutter

,

4.5KW Double Edge Cutting Machine

RC-100D double cutter edge board re-cutting machine

Hydraulic driving



Characteristics:

  Paper protector re-cutter is to re-cut paper edge protector into small pcs.

  Feeding is driven by servo motor.

  Cutting is controlled by PLC, hydraulic driving.



Specification:

Model RC-100D
Applicable paper edge size 25-100mm
Max. cutting thickness 8mm
Max. continuous cutting speed 6000mm/min
Minimum cutting length 50mm
Cutting accuracy ±1mm
Power 4.5KW
Dimension 2000×1150×1625mm
Weight 400KG



Photos:
