Product Details:
|
| Power Supply: | 380V OR 220V OR 415V | Color: | Customized |
|---|---|---|---|
| Color Quantity: | 2 Colors | Max. Printing Width: | 760mm |
| Max. Printing Length: | 200-960mm (38”) (pls Confirm Length) | Printing Speed: | 5-60m/min |
| Voltage: | 220V Or 380V Or 415V | ||
| Highlight: | Two Colors Flexographic Printing Machine,Flexographic Printing Machine 60m/Min |
||
Two Colors Flexographic Printing Machine
Model: YT2-800MT
Characteristics:
1. Easy operation, flexible starting, accurate color register.
2. The meter counter can set printing quantity according to the requirements.
Stop the machine automatically at the quantity or when the material is cut off.
3. Printing cylinder lift and lower, it will stir the printing ink automatically after lifting.
4. The printing ink is spread by the anilox cylinder with even ink color.
5. Reliable drying system coordinated with high-speed rotation, it will automatically break circuit when the machine stops.
6. 360°continuous and adjustable longitudinal register device.
7. The motor has inverter controller with different speed
8. The electric board has buttons and make the machine easy and effective.
Specification:
| Main Technical Parameters | |
| Color quantity | 2 colors |
| Max. printing width | 760mm |
| Applicable Raw material |
Biodegradable film, HDPE film, LDPE film Pvc: 35~70μm Opp: 20~70μm Bopp: 20~60μm Pe: 35~100μm Ny: 20~50μm Pet: 20~60μm Cpp:20~60μm Paper: 20~350g/㎡ al foil: 20-250 mic |
| Max. Printing length | 200-960mm (38”) (pls confirm length) |
| Printing speed | 5-60m/min |
| Thickness of plate | 2.28mm+0.38mm (pls confirm plate thickness) |
| Power supply | 380v 50hz 3pahse (pls confirm Power) |
| Machine size | 2300mm x 1800mm x 2300mm (l x w x h) |
| Machine weight | about 1200kgs |
| Unwind Unit | |
| Width of rollers | 800mm |
| Effective print width | 760mm |
| Dia. of roller | 76mm inner size |
| Max diameter of unwind | 800mm |
| Type of unwind | manual loading |
| Single unwinding | Optional automatic loading |
| Automatic tension controller for your option. | |
| Printing Unit | |
| Constitution of printing | chrome plated roller, rubber roller, metal anilox roller, plate-glued roller |
| Girth of pressing roller | 200-960mm (pls confirm if you want to print wider) |
| Material of plate | resin and rubber, standard 2.28mm+0.38mm (pls confirm material and confirm the thickness) |
| Principle of work | straight gears drive |
| Type of chromatically | 360 degree circulating |
| Plated-glued roller adjusting | pneumatic automatic way |
| Heating and Drying Unit | |
| Type of heating and drying | blowing and heating |
| Heating zones | heating tubes 2 zones / Electric heating |
| Assistance of drying length | 1m |
| Blowers | for dry system |
| Electrical Parts | |
| Main motors | 1.5kw, AC motor with inverter |
| Ink-transfer motor | 0.37kw with reduce gear system |
| An speed adjustable inverter equips with the main motor | |
| Rewind Unit | |
| Max. Length of roller | 800mm |
| Max. Length of effective roller | 760mm |
| Dia. of roller | 76mm inner size |
| Max. Dia of wind | 600mm for film |
| Way of rewind | manual unloading / Single rewinder: optional automatic rewinding |
| Shaft | steel rollers with two plugs (air shafts for your option) |
| Meter counter | |
| Electrical Parts | |
| Inverter | KEWO China Famous brand |
| Electric parts | CHNT best china brand |
| Motor | Shanghai High quality brand |
Optional part:
1) Paper edge trimming device with fan
With this device, customer can do slitting and rewinding in the same time.
Two Air expanding shaft will be equipped for unwinding and rewinding
Minimum slitting width: 100mm
2) Automatic loading system
3) Automatic unloading system: Paper reel diameter no more than 450mm
Automatic loading and unloading device with Magnetic powder brake
When material weight is around 1000KG and people cannot hold it, need to consider use the automatic loading and unloading device
This magnetic powder brake can help to get better rewinding tension.
4) Automatic tension control system
This device can help getting perfect rewinding and keep good rewinding tension.
Usually, edge guiding device will work together with Automatic loading and unloading device with Magnetic powder brake.
Our film printing samples:
